ASI BAC855 controller

Turime

The BAC855 is a high-performance sub-compact AC Motor Controller / Inverter and employs the latest in Field-Oriented Vector Control (FOC) and ASI’s proprietary adaptive Sensorless Motor Control Algorithm. ASI Controllers feature auto-tuning and can deliver up to 120% of a Motor’s rated maximum locked rotor torque without the need for complicated position sensors. The BAC855 is designed to handle the highest commercial tier of electric bikes, delivering more power for these demanding applications.

ASI BAC800/855 Wiring Harness sold separately.

NO BACDOOR APP CREDENTIALS PROVIDED

SVARBU
Naudojant šį gaminį su sistema ar atnaujinimo rinkiniu, kuris nebuvo pirktas iš mūsų – FabiRide.lt parduotuvės, pakeitus valdiklį garantija nesuteikiama.

Jei norite įsigyti šią prekę, turite įsigyti nuotolinio programavimo seansą.



Nom. Voltage 36 – 72V Volts
Nom. Current 70 Amps
Peak Current 90 Amps
TTL Yes
Auto Tuning Yes
Sensorless Start Adaptive
IP Rating IP65 (IP67 with sealed connectors)
QC Verification 100% EOL Test under load
Additional Available Protocols TTL + Bluetooth
